SCSI Commands
5-140
Quantum DLT 7000 Tape System
5.16
RECEIVE DIAGNOSTIC RESULTS COMMAND (1Ch)
The RECEIVE DIAGNOSTIC RESULTS command fetches the results of the last
SEND DIAGNOSTIC command sent to the tape drive.
Bit
Byte
7
6
5
4
3
2
1
0
0
Operation Code (1Ch)
1
Logical Unit Number
Reserved
2
Reserved
3 - 4
(MSB)
Allocation Length
(LSB)
5
Unused
Reserved
Flag
Link
Figure 5–69 RECEIVE DIAGNOSTIC RESULTS Command Descriptor Block - Data
Format
Table 5–67 RECEIVE DIAGNOSTIC RESULTS Command Data - Field Descriptions
Field Name
Description
Allocation Length
Specifies the number of bytes of diagnostic page results
the drive is allowed to send to the initiator.
