General Description and Specifications
1-6 Quantum DLT 7000 Tape System
Table 1 −6 DLT 7000 Operating Shock and Vibration Specifications
Specification Description
Shock
Pulse Shape: ½ sine pulse
Peak Acceleration: 10 G
Duration: 10 ms
Application: X,Y,Z axes, once in each axis
Vibration
Type: Sine Sweep
Frequency Range: 5 to 500 Hz Upward and downward sweep
Acceleration level: 0.25 G
0.010” DA Between 22 and 500 Hz
Between 5 and 22 Hz (crossover)
Application: X,Y,Z axes Sweep rate = 1 octave per minute
Vibration (Overstress)
Type: Sine Sweep
Frequency Range: 10 to 500 Hz Upward and downward sweep
Acceleration level: 0.50 G
0.010” DA Between 26.1 and 500 Hz
Between 5 and 26.1 Hz (crossover)
Application: Vertical axis
(top/bottom) Sweep rate = 1 octave per minute
