253
Network Installation Appendix A
Transceiver Installation Examples
The following illustrations show examples of installing transceivers in the ceiling and under the floor.
Inspection opening
Secured wooden board
Mount near an inspection
opening large enough to
enable maintenance.
Secured wooden board
Free-access Floor Installation
Ceiling Installation
