Page 44

5.0
10/100M SPECIFICATIONS
Plug-in Module
Standalone Tabletop
Standalone Wall-Mount
Description
10/100BASE-TX UTP to 100BASE-FX Fiber Media Converter with integrated management
Protocols
10BASE-T, 100BASE-TX,100BASE-FX with 1536 bytes max. frame size
Cable Types
UTP
EIA/TIA 568A/B, Category 5 and higher
Fiber
Multimode: 50/125, 62.5/125, 100/140 um,
Single-mode: 9/125 um
Serial
RS-232, 22 to 24 AWG, 12 to 50 pF/ft.
Connector Types
UTP
RJ45
Fiber
SFP:
Dual Fiber:
Single Fiber:
LC
SC, ST, LC, MT-RJ
SC
Serial
Mini DIN-6 female,
mini DIN-6 male to DB-9 female adapter included
Controls
DIP-Switches and LEDs
802.1p Priority Levels and
VID Priority Level Groups
4 Levels
(PRI 0-1, 2-3, 4-5, 6-7)
Power Requirements
DC Power
1.0A @ 3.3VDC
Nominal: 0.6A @ 9VDC
Voltage Range: 8 - 15VDC
DC Power Connector
Power supplied by backplane
2.5mm Barrel Connector or Terminal Connector
AC Power Adapter [US]
N/A
100-120VAC/60Hz
0.07A @ 120VAC
AC Power Adapter
[Universal]
N/A
100-240VAC/50-60Hz
0.07A @ 120VAC
Dimensions
W: 2.8" x D: 4.5 "x H: 0.85"
W: 3.1" x D: 4.8" x H :1.0"
W: 3.8" x D: 4.8" x H: 1.0"
Weight
without power adapter
8 oz.
1 lb.
with power adapter
N/A
1.5 lb.
Compliance
UL, CE, FCC Class A
IP-Based Management
Telnet; SNMPv1, SNMPv2c, SNMPv3
Temperature
Operational - Commercial
0 to +50
o
C
Operational - Wide Range
-40 to +60
o
C
Operational - Extended
-40 to +75
o
C
Storage
-40 to +80
o
C
Humidity (non-condensing)
5 to 95%
Altitude (Operational)
-100m to 4,000m
MTBF [hrs]
without power adapter
600,000
with power adapter [US]
N/A
250,000
with power adapter [Unv]
N/A
100,000
