Module - iConverter 10/100M
iConverter, Serial Agent
Identifier -
Chassis Number
= 1
Switch
ON Condition
OFF Condition
H/W
Actual
Slot Number
= 1
1: Pause Enabled
Pause Disabled Off
Off
Model Number
= 8919-0
2: Fiber HDX
Fiber FDX
Off
Off
3: UTP Manual
UTP Auto-Neg
Off
Off
Serial Number
= xxxxxxxx
4: UTP 10 Mbps
UTP 100 Mbps
Off
Off
Manufacturing Date = xxxxxxxx
5: UTP HDX
UTP FDX
Off
Off
Product Revision
= x
6: Link Propagate
Link Segment
Off
Off
Software Revision
= xx
7: Remote Fault
Normal
Off
Off
8: Symm Fault Det
Normal
Off
Off
LED
9: BP A Enabled
BP A Disabled
On
On
1: Power
= On
10: BP B Enabled
BP B Disabled
On
On
2: Power Supply 1
= Off
11: Not Available
3: Power Supply 2
= Off
12: Slave Only
Master/Slave Off
Off
4: Power Supply 3
= Off
13: Not Available
5: Fiber Link
= Off
14: Not Available
6: BP Master
= On
15: Not Available
7: UTP 10 Link
= Off
16: Not Available
8: UTP 100 Link
= Off
OAM settings:
9: UTP FDX
= Off
17: IP Protocol State On
18: Management Mode Secure OAM
Toggle Switch(1-16), (I)dentifier, (R)eset, (H)elp, (P)ortStat, Port(C)tl >
The Module configuration screen provides general information concerning the configuration and status of
the module. The screen displays the model and serial numbers, hardware and software revisions, as well as
the condition of the LEDs and DIP-switches. The DIP-switches can be re-configured (options 1 - 10, 12)
without removing the module from the chassis. Select the appropriate option to change the DIP-switch
setting. Selecting DIP-switch options 1 - 10 and 12, will cause the selection to change states under the
‘Actual’ heading.
NOTE: The Plug-In Module configuration screen is shown. The standalone Module configuration
screen will display LED 2, 3, 4, and 6 and DIP-switches 9, 10 and 12 as NOT AVAILABLE.
