4.3.1
Port Access
The Port Access option allows the ports to be disabled/enabled while maintaining the port configuration
and network link
To configure Port Access, select option 1 for the Fiber port and option 2 for the UTP port from the Port
configuration screen.
4.3.2
Bandwidth Control
The 10/100M Bandwidth Control is accessed by selecting options 21 - 24 or 14 - 17 depending on the
module type; plug-in or standalone.
The 10/100M provides separate ingress and egress rate control on each port.
Ingress values will be displayed when the option is selected. Values of 128Kbps, 256Kbps, 512Kbps,
1Mbps, 2Mbps, 4Mbps, 8Mbps and Full bandwidth are available.
Egress values will be displayed when the option is selected. Values of 128Kbps, 256Kbps, 512Kbps,
1Mbps, 2Mbps, 4Mbps, 8Mbps and Full bandwidth are available.
Module - iConverter 10/100M iConverter, Serial Agent
Identifier -
Chassis Number
= 1
Port VLAN Path Setup
Slot Number
= 11 ----------------------------------
Model Number
= 8919-0
11: Fiber to UTP
Enable
On
12: Fiber to BP A
Enable
On
Port Access Control Setup
13: Fiber to BP B
Enable
On
----------------------------------
14: UTP to BP A
Enable
On
1: Fiber Enable
On
15: UTP to BP B
Enable
On
2: UTP Enable
On
16: BP A to BP B
Enable
On
17: Fiber to Mngmnt
Enable
On
Enhanced Features
18: UTP to Mngmnt
Enable
On
----------------------------------
19: BP A to Mngmnt
Enable
On
3: 802.1Q Processing Enable
Off
20: BP B to Mngmnt
Enable
On
4: Configure Tag VLAN Control
5: Configure VLAN Membership
Bandwidth Control
6: Save TAG VLAN parameters --------------------------------
7: Configure 802.3ah parameters
21: Ingress rate Fiber
No Limit
8: Configure 802.3ah events
22: Egress rate Fiber
No Limit
9: SFP Information
23: Ingress rate UTP
No Limit
10: cNode Loopback
24: Egress rate UTP
No Limit
Enter Choice, Previous Screen(0), (H)elp, E(x)it >21
New Rate (0= No Limit, 1=128Kbps, 2=256Kbps, 3=512Kbps,
4=1Mbps, 5=2Mbps, 6=4Mbps, 7=8Mbps) > 0
Page 29
