d Adding Staples
139
6
• 3: Hold both sides of the cartridge.
• 4: Pull up the upper unit of the cartridge.
• 5: Take out the empty refill in the arrow di-
rection.
• 6: Align the arrows on the new refill and
the cartridge, and then push in the refill
until it clicks.
• 7: Gently push down the upper unit into
the cartridge.
• 8: Pull out the ribbon.
• 9: Hold the green lever while pushing in
the cartridge until it clicks.
• 10: Close the front cover of the finisher.
ZCAJ050E
ZCAJ060E
ZCAJ070E
ZCAJ080E
ZCAJ090E
ZCAJ100E
