Troubleshooting
124
6
Inserting Toner
• 1: Hold the new bottle horizontally and
shake it from side to side five or six times.
Note
❒ Do not remove the black cap before
shaking.
• 2: Remove the black cap.
Note
❒ Do not remove the inner cap.
• 3: Put the toner bottle on the holder, and
then pull its top forward.
• 4: Push in the green lever until it clicks.
Note
❒ Before lowering the toner holder lever, be
sure to push the toner holder fully in.
• 5: Lower the toner holder lever back into its
original position.
• 6: Close the machine's front cover.
ZHWT010E
ZHWT020E
ZHWT030E
ZHWT040E
ZHWT050E
