BATT. RELEASE
B
C
AUDIO
JLIP
RF
DC OUT
VIDEO
LE
N S
C
O V E R
SP•SLP TRACKING
TER R/M
W.BAL. PLAY/PAUSE STOP FF
+
REW
+ –
CAMERA
VCR
POWER
OFF
SNAP SHOT
10
JLIP Jack
Handstrap
Thumb Trigger
AUDIO, RF DC OUT, and
VIDEO Jacks
BATT. RELEASE Button
Shoulder Strap
Attachment Ring
Clock Cell
Compartment
Shoulder Strap
Attachment Ring
Attach Battery Here
DC In Jack (Attach AC
Adapter/Charger Here)
POWER (VCR/OFF/CAMERA) Switch
and Indicator
First-Time Operation
14. Review camcorder’s operating controls.
(continued)
Model CC639 Only:
B (Bright) and C (Color) Controls
on Bottom of Viewfinder
See Trouble Checks for details.
SNAPSHOT Button
