background image

EZ2110 Series

RCA Small Wonder Camcorder

www.mysmallwonder.com

Congratulations on purchasing your new RCA High Defi nition Small Wonder Camcorder.

Please read these instructions for quick tips on using the product.

The User Manual PDF fi le can also be found in the camcorder memory under the User Manuals folder.

Please charge the battery for at least four hours before fi rst use.

QuickStartGuide

1. Content of the box

• Small

Wonder

Camcorder

• USB

cable

• AV

cable

• Tripod mount bracket
• 2 GB micro SD card (Installed in device)

• Software

DVD

• User

Manual

• Quick Start Guide
• Owner Registration card
• Warranty

leafl et

2. Charging your camcorder

3. General controls

Lens

Video
quality
selector

Recording indicator

Microphone

microSD card slot

Camcorder strap hole

On/off switch*

Delete recordings

Take photo

AV output

Playback/pause

Setup menu

Record

Audio speaker

LCD screen

USB and HDMI
video output

+/ – Adjust volume
during playback/
zoom during record
and preview

/ – Skip to

previous or next
recording; fast rewind
or forward

* To reset the camcorder (in case it is not functioning properly):
Slide and hold the On/off switch for more than 10 seconds.

2

Actual recording time and capacity will vary depending on type of video content being recorded, system requirements,

and other factors.

6. Selecting recording quality

Battery indicator

Memory card indicator

Selected recording quality

Settings

HD

HQ

WebQ

Resolutions (pixel) &
Frame Rates (FPS)

1280 x 720 @ 30fps

720 x 480 @ 30fps

320 x 240 @ 30fps

Approx. recording durations
on a 2 GB memory card

2

Up to 1 hours

Up to 1.7 hours

Up to 5 hours

Preview mode

5. Turning on the camcorder

Slide and
hold until the
camcorder turns
on or off

4. Inserting (or removing) memory card

A micro SD memory card (supplied) is recommended for recording.

As the memory card is small in size, it is recommended to use a small coin to help insert or remove it.

To insert card: Push the card in until a click is heard

To remove card: Push card in until a click is heard, then slowly release
the card. As card is under minimal tension when locked in memory
slot, please use care when removing.

Lift up the cover

NOTE:
The unit is properly charging when you
see the animated charging symbol on the
Camcorder display.
If you do not see this charging symbol, follow these
steps:

1. Make sure that you have the camcorder

connected to the computer USB port through
USB cable, and the computer is turned on.

2. Momentarily slide and hold the Camcorder power

switch to the ON position to initiate charging.

The camcorder has two operation modes (Preview and
Playback). It is always in Preview mode after switched on.
Refer to the diagram below for switching between modes.

Switch on

Auto timeout

Press PHOTO

Press PLAY/PAUSE

Playback mode

Press PHOTO /

Press Record

Preview mode

1

Take a photo

1

In Preview mode, press Record to record a video.

v2.0 (1.0.2.0) (EN)

English

USB port of your
computer

USB cable
