RCA CC638/639 - Manual (Page 110)

108
Specifications
General
Power requirement: 6VDC
Power consumption:
Model CC638: 5.7 watts (normal)
Model CC639: 5.9 watts (normal)
Weight: Model CC638: 1.74 lbs. (800g)
Model CC639: 1.7 lbs. (780g)
Dimensions – Including Viewfinder
Model CC638:
4-3/8"(W) x 4-1/2"(H) x 9"(D)
111 (W) x 113 (H) x 226(D) mm
Model CC639: 4-3/8"(W) x 4-1/2"(H) x 8-1/2"(D)
111 (W) x 113(H) x 206(D) mm
Video Recorder Section
Format: VHS-C
Record/Playback System:
Four video record/playback heads
One flying erase head
Video Signal: EIA Standard NTSC
color
Viewfinder
Model CC638: .5" Black & White
Model CC639: .55" Color – 113K Pixel
Camera Section
Image Sensor: 1/4" CCD Imager
Tripod Mount: One 1/4" x 20 threaded
hole
Lens: F1/1.2
14:1 (4.1-57.4 mm)
Filter Diameter: 46 mm
AC Adapter/Charger
Power requirement: 100-240 V, 50/60 Hz.
Power consumption: 23 watts
Weight: .7 lbs. (320g)
Dimensions:
6"(W) x 1.7"(H) x 2.7"(D)
150 (W) x 42(H) x 68(D) mm
