54
Various Settings (Function mode)
The VR-700 contains a three-band equalizer. When you turn on the EQ Switch (equalizer switch), the equalizer will apply to all organ
sounds, ensemble sounds, and the playback of the player.
With the Group already selected, press the [+] button or [–] button until is shown in the display.
* Settings for the following parameters are saved in system memory. After editing these, press the [WRITE] button to save the settings in
system memory (p. 51).
* The shaded parameters are stored in system memory.
With the Group already selected, press the [+] button or [–] button until is shown in the display.
* Settings for parameters other than Bend Range are saved in system memory. After editing these, press the [WRITE] button to save the
settings in system memory (p. 51).
* The Bend Range setting is saved separately for each favorite.
* The shaded parameters are stored in system memory.
Equalizer Settings
Button Parameter Value Factory setting
[PIANO] EQ Switch OFF, ON OFF
[E.PIANO] EQ Input Gain -15–0–+3 (dB) 0 (dB)
[STRINGS] EQ Low Gain -12–0–+12 (dB) 0 (dB)
[CHOIR/SCAT] EQ Mid Freq
200, 250, 315, 400, 500, 630, 800 (Hz)
1.00, 1.25, 1.60, 2.00, 2.50, 3.15, 4.00, 5.00, 6.30, 8.00 (kHz)
800 (Hz)
[BRASS] EQ Mid Gain -12–0–+12 (dB) 0 (dB)
[SYNTH LEAD] EQ High Gain -12–0–+12 (dB) 0 (dB)
Pedal, Bend Lever, and Foot Controller Settings
Button Parameter Value Factory setting
[PIANO] Damper Pedal Polarity : Normal
: Reverse
Normal
[E.PIANO] Control Pedal Polarity Normal
[STRINGS] Control Pedal Assign
Refer to “Functions that can
be assigned to the control
pedal” (p. 55)
Rotary speed
[CHOIR/SCAT] Bender Range 0–24 (semitones) –
[BRASS] D Beam Sensitivity 1–127 127
