65
Making a Multi-Track Recording
Making a Multi-Track
Recording
Adjusting the Tone of Each Track
A selectable 2-band/3-band parametric equalizer is provided for each
channel. Here’s how to use the equalizer to adjust the tone of each track.
fig.3-31
1
Press [FADER/MUTE] so that the TR (track) indicator is lit or
blink.
2
Press the [SELECT (CH EDIT)] button for the track channel
whose equalizer you wish to adjust. [SELECT (CH EDIT)] will
light, and the Track Mixer display will appear.
3
Press [F2 (Low)]. If [F2] does not show “Low,” first press
[PAGE] so that “Low” is displayed, and then press [F2 (Low)].
4
Press [ENTER/YES].
fig.3-32.e_80
3 2 1 4
You can use three-band EQ
on as many as 16 tracks
and/or inputs at the same
time. Three-band EQ
cannot be used on Tracks
17 and 18. Two-band EQ
can be used on all 28 tracks
and inputs at the same
time.
Switch Selector
Low-range
Middle-range
High-range
Gain
Frequency
Q (the sharpness of the change)
