12
Preparations
Basic Connections (Power Supply,
Audio Devices and Headphones)
fig.1-08.e
If you are using headphones, connect them to the rear panel PHONES jack.
The PHONES jack will output the same signal as the MONITOR jacks.
When you purchase the VS-1824, it will be set so that all analog audio
signals are output from the MASTER jacks. The MONITOR jacks will output
the same sound as the MASTER jacks.
Stereo Set, etc. To Power Outlet
Stereo Headphones
(RH-25, RH-50, etc.)
To prevent malfunction
and/or damage to speakers
or other devices, always
turn down the volume
before making any
connections.
For details refer to
“Determining Output”
(Owner’s Manual p. 72).
