Appendix A

Device-Specific Information

A-14

ni.com

Note

For more information about default NI-DAQmx counter inputs, refer to Connecting

Counter Signals in the NI-DAQmx Help or the LabVIEW Help in version 8.0 or later.

Table A-5. Default NI-DAQmx Counter/Timer Pins

Counter/Timer Signal

Default Terminal Number (Name)

CTR 0 SRC

1 (PFI 0)

CTR 0 GATE

2 (PFI 1)

CTR 0 AUX

34 (PFI 9)

CTR 0 OUT

6 (PFI 4)

CTR 0 A

1 (PFI 0)

CTR 0 Z

2 (PFI 1)

CTR 0 B

34 (PFI 9)

CTR 1 SRC

4 (PFI 3)

CTR 1 GATE

3 (PFI 2)

CTR 1 AUX

35 (PFI 10)

CTR 1 OUT

7 (PFI 5)

CTR 1 A

4 (PFI 3)

CTR 1 Z

3 (PFI 2)

CTR 1 B

35 (PFI 10)

FREQ OUT

8 (PFI 6)
