Chapter 8 Counters
© National Instruments Corporation 8-33 NI USB-621x User Manual
Cascading Counters
You can internally route the Counter n Internal Output and Counter n TC
signals of each counter to Gate inputs of the other counter. By cascading
two counters together, you can effectively create a 64-bit counter. By
cascading counters, you also can enable other applications. For example,
to improve the accuracy of frequency measurements, use reciprocal
frequency measurement, as described in the
Method 3 bullet of the
Frequency Measurement section.
Counter Filters
You can enable a programmable debouncing filter on each PFI signal.
When the filters are enabled, your device samples the input on each rising
edge of a filter clock. USB-621x devices use an onboard oscillator to
generate the filter clock with a 40 MHz frequency.
Note NI-DAQmx only supports filters on counter inputs.
The following is an example of low to high transitions of the input signal.
High to low transitions work similarly.
Assume that an input terminal has been low for a long time. The input
terminal then changes from low to high, but glitches several times. When
the filter clock has sampled the signal high on N consecutive edges, the low
to high transition is propagated to the rest of the circuit. The value of N
depends on the filter setting; refer to Table 8-5.
The filter setting for each input can be configured independently. On power
up, the filters are disabled. Figure 8-29 shows an example of a low to high
transition on an input that has its filter set to 125 ns (N = 5).
Table 8-5. Filters
Filter Setting
N (Filter Clocks
Needed to
Pass Signal)
Pulse Width
Guaranteed to
Pass Filter
Pulse Width
Guaranteed to
Not Pass Filter
125 ns 5 125 ns 100 ns
6.425
μs
257 6.425
μs
6.400
μs
2.56 ms ~101,800 2.56 ms 2.54 ms
Disabled — — —
