Appendix A Device-Specific Information
© National Instruments Corporation A-9 NI 6124/6154 User Manual
Note For more information about default NI-DAQmx counter inputs, refer to Connecting
Counter Signals in the NI-DAQmx Help or the LabVIEW Help in version 8.0 or later.
For a detailed description of each signal, refer to the NI 6154 I/O Connector
Signal Descriptions section of Chapter 3, I/O Connector .
CTR 0 B 33 (PFI 2) P0.2
CTR 1 SRC 15 (PFI 3) P0.3
CTR 1 GATE 34 (PFI 4) P0.4
CTR 1 AUX 35 (PFI 5) P0.5
CTR 1 OUT 36 (PFI 7) P1.1
CTR 1 A 15 (PFI 3) P0.3
CTR 1 Z 34 (PFI 4) P0.4
CTR 1 B 35 (PFI 5) P0.5
Table A-2. NI 6154 Device Default NI-DAQmx Counter/Timer Pins (Continued)
Counter/Timer Signal Default Pin Number (Name) Port
