BLSR single span Fiber cut example
Step
Action
9
Node 3 receives the ‘
Bridged’ status indication from Node 4. Node 3 enters
into the ‘
Bridged and Switched’ state. Traffic received on the protection
channels are then routed as if they were received from the failed working link.
Node 4 then sends a message to Node 3 indicating that it has entered into
the ‘
Bridged and Switched’ state.
•
source node (Node 3)
•
destination node (Node 4)
•
type of switch request (Signal Degrade)
•
path direction (Long)
•
node status (’
Bridged and Switched’)
Note: Depending on the cross-connects provisioned, Node 3 will then either
drop traffic at the add/drop multiplexer or route traffic back out onto the
working channels of the ring.
10
Switch is complete.
—end—
