3-36 Hardware feature descriptions
OPTera Metro 3500 Multiservice Platform NTRN10AN Rel 12.1 Standard Iss 1 Apr 2004
Figure 3-18
DS1 29-84 Rear I/O module (NTN452FA)
EX1155p
Figure 3-19
8xRJ-45 Rear I/O module (NTN452HB)
EX1155p
In (DS1 57-84)
Alignment
tab
Out (DS1 29-56)
In (DS1 29-56)
Out (DS1 57-84)
Lock/eject
lever
Port 5
Port 6
Port 7
Port 8
Port 1
Port 2
Port 3
Port 4
Lock/eject
lever
Alignment tab
