4.2.2 Ribbon Menu
The Ribbon Menu is accessed by pressing the Menu button on the remote control. The Left and
Right buttons are used to move across the ribbon menu. The Select button is used to select the
desired menu. To hide the Ribbon Menu press the Menu button
or the Focus button . It is
possible to wrap around from one side of the Ribbon Menu to the other side. For example, if you press
the Left button while the Select Destination Icon is highlighted, the Ribbon Options Icon will be
highlighted. Not all of the icons shown below will be visible in the Ribbon Menu at all times. For
example, the Simulator Icon is only displayed when in simulator mode. Also, the Ribbon Options Menu
can be used to disable icons that you don’t use often.
4.2.2.1 Select Destination Icon
The Select Destination Icon is used to change the waypoint to which the software is navigating.
This is used mostly for “free flying” between waypoints – not when navigating through the waypoints
in a pre‐declared task. It is also often used when flying a task, but low and in need of a nearby airport
at which to land.
Note that the Task Window at the bottom of the moving map screen is used to
move through the waypoints in a pre‐defined task.
The Select Destination Window has 2 tabs. The Distance List Tab lists the waypoints sorted by distance
from your current location. The Alphabetical List Tab lists the waypoints alphabetically.
or
