108 / Specifications
MICS-XC Norstar-Companion Installer Guide P0881594 Issue 01
Base Station
The Base Station consists of two printed circuit boards: the
Line Interface Module (LIM) and the Dual Radio Interface
Module (RIM). The Base Station provides connectors for a
terminating line cord, external antennas, and a power supply
cord. Only passive antennas may be connected to the antenna
sockets on the Base Station.
Base Station plug-top power supply
If a plug-top power supply is required, use only the power
supply recommended for use with the Base Station. Other
usage invalidates any approval given to this apparatus.
Part no. NTAE20AA (A0401506 in the US)
NT0P30DA-93 (A0403378 in Canada)
Color Dolphin Gray
Height 20 cm (8 in.)
Width 32 cm (12 in.)
Depth 5 cm (2 in.)
Weight less than 1 kg (less than 2 lbs)
Input voltage 12 to 50 V DC
Maximum loop length (TCM) 1143 m (4,000 ft.)
Operating temperature 5 °C
to 40
°C (
+32°F to +120°F)
Relative humidity 5 to 85% (condensation may occur)
Peak power rating 15 dBm
Part no. A0386334
Color Dolphin Gray
