52 Adding and replacing DC power supplies
313070-E Rev 00
Figure 32 Removing the DC power supply from the 8006 and 8010 chassis
14 Install a new power supply (see “Installing the DC power supply” on page 32 )
or install a power filler panel (see “Removing and installing a power filler
panel” on page 29 ).
Replacing the bottom bezel (8010co chassis)
Choose one of the following procedures for the specified bezel model:
Replacing bezel model 312096-A
To replace the bottom front bezel:
1 Hook the two bezel slots on the two chassis tabs ( Figure 33 on page 53 ).
Note: The 8005DC power supplies require a modified air intake bezel.
If you have installed Model 8005DC power supplies (1500 W) in the
8010co chassis and have air intake bezel imprinted with 312096-A, or if
you have difficulty installing the bezel over the 8005DC power supplies,
you can order modified bezel model 321325-A (Order Code
DS1411027).
9432FA
+DC
-DC
