Figure 27, Figure 28 – Nortel Networks 8000 Series User Manual
Page 49
Adding and replacing DC power supplies
49
Installing a DC Power Supply in an Ethernet Routing Switch 8000 Series Chassis
9
Lift the extractor lever to disconnect the power supply from the backplane
connector (
and
Figure 27 Disconnecting the DC power supply from the backplane: 8010co
chassis
Figure 28 Disconnecting the DC power supply from the backplane: 8006 and
8010 chassis
10 Slide the power supply partway out of the chassis.
10337FA
+DC
-DC
9432FA
+DC
-DC
