82 Adjustments and Settings for Recording : Selection of video output signals
The MON OUT connector outputs down-converted analog
signals.
Set the video signals output from the MON OUT connector
by using the MONITOR OUT item on the menu (SEL> screen on the SYSTEM SETTING page).
Set to superimpose characters to the VBS signals output
from the MON OUT connector in the MONITOR OUT
CHARA item of the menu ( screen on the
SYSTEM SETTING page).
Settings of signals output from MON OUT connector
Item
Variable
range
Remarks
MONITOR OUT VBS
VF
Y Set video signals output from the
MON OUT connector.
VBS: Analog composite signals are
output.
VF: Y signals to be output to the
viewfinder is output. The
status screen is also
superimposed.
Y: Analog HD-Y signals are
output.
Item
Variable
range
Remarks
MONITOR OUT
CHARA ON
OFF Superimpose characters on the VBS
output signals from the MON OUT
connector.
ON: To superimpose
OFF:Not to superimpose
‹ Note
This does not link with the VIDEO
OUT CHARACTER switch.
