157 Menu : Menu Description Tables
Me
n
u
*1 This variable range is the numerical values for 59.94 Hz.
For 50 Hz, the frame rate is up to 24f. The frame rate is
up to 23f in 24PN (Native) mode.
The ____ in the Adjustable Range column indicates the
preset mode.
Note
Displayed REC TIME, PAUSE TIME and TOTAL REC TIME
are translated into either drop-frame or non-drop-frame
according to the mode of operation.
TAKE TOTAL TIME is actual time. Therefore, TOTAL REC
TIME may incorporate fractions, depending on the settings.
REC FUNCTION
Items/
Data Saved
Adjustable
Range
Remarks
INTERVAL
REC MODE ON
ONE SHOT
OFF Sets INTERVAL REC function.
ON: Uses internal memory to perform
interval recording.
ONE SHOT:
Performs “one-shot” recording for the
duration specified under REC TIME,
and then stops.
OFF: INTERVAL REC is not performed.
‹ Note
This item cannot be changed when [ON]
is selected in LOOP REC MODE.
– C U F –
INTERVAL
REC HOLD ON
OFF Selects whether INTERVAL REC MODE
settings are retained or not when the
power is turned off once.
ON:
Retain
OFF: Do not retain. The INTERVAL
REC MODE is OFF whenever the
power is turned on again.
– C U F –
REC TIME* 1 00s01f
:
59s29f Set REC TIME (1 cut).
‹ Note
However, the settings can be made frame
by frame, and the numbers of the cut-off
unit frames for the shortest time period
and the set time on the actual operation
may vary with the recording method. For
details, refer to [Interval Recording] (page
36).
– C U F –
PAUSE TIME* 1 00h00m00s01f
:
00h04m59s29f
:
23h59m59s29f Specify PAUSE time for recording.
‹ Note
However the settings can be made frame
by frame, and the numbers of the cut-off
unit frames for the shortest time period
and the set time on the actual operation
may vary with the recording method. For
details, refer to [Interval Recording] (page
36).
– C U F –
TAKE TOTAL
TIME NONE
:
5day Specify the time needed for shooting.
Select from NONE (continue until
operation is manually stopped) to 5 days.
– C U F –
TOTAL REC
TIME* 1
00m00s01f
:
99m59s29f
OVER100min
NONE Display total recorded time. The setting
cannot be changed using this option.
Displays the recording time (recording
time needed for the P2 card) calculated
using REC TIME, PAUSE TIME, and
TAKE TOTAL TIME.
‹ Note
A value based on actual processing is
displayed
. – – – – –
AUDIO REC ON
OFF Select whether or not sound will be
recorded.
– C U F –
START DELAY 0SEC
:
10SEC
Set the delay after pressing REC START
to start recording in INTERVAL REC.
– C U F –
PRE REC
MODE ON
OFF Select whether or not to enable PRE
RECORDING.
ON: PRE RECORDING enabled.
OFF: PRE RECORDING disabled.
‹ Note
Specify the PRE RECORDING time by
using the menu option PRE REC TIME.
– C U F –
Items/
Data Saved
Adjustable
Range
Remarks
PRE REC
TIME 1SEC
:
8SEC
:
15SEC
Set PRE RECORDING.
1-15SEC:
Set the length of time that can be
retrospectively recorded before the
REC START button is pressed.
‹ Note
When the SYSTEM MODE menu option
on the SYSTEM MODE screen is set to
1080-59.94i, 1080-50i, 720-59.94P, or
720-50P, or when it is set to 480-59.94i
or 576-50P and the REC MODE menu
option is set to DVCPRO50, the upper
limit of the above recording time is 8
seconds.
– C U F –
LOOP REC
MODE ON
OFF Select whether or not to enable LOOP
REC.
This setting can be used with PRE
RECORDING features.
ON: Enable LOOP REC.
OFF: Disable LOOP REC.
‹ Notes
z After the power is turned off, this item
will default to OFF the next time the
power is turned on.
z This item cannot be changed when
[ON] or [ONE SHOT] is selected in
INTERVAL REC MODE.
– – – F –
REC START ALL
NORMAL Select operating modes that allow
recording to start.
ALL: Allow recording to start during
stop, recording pause, and
playback.
NORMAL:
Allow recording to start during stop
and recording pause.
‹ Note
Even if this is set to [ALL], the operation is
[NORMAL], when [ON] or [ONE SHOT] is
selected in INTERVAL REC MODE.
– C U F –
P.ON REC
SLOT SEL HOLD
SLOT1 Select the recording order of the slot
when the power is turned on.
HOLD:
The recording order starts with the
card previously selected when the
power was turned off.
SLOT1:
The recording order starts with the
card that is inserted in Slot 1 when the
power is turned on.
– C U F –
Example of drop-frame
REC TIME 02s00f
PAUSE TIME 02s00f
TAKE TOTAL TIME 40min
TOTAL REC TIME 19m59s06f
