177 Menu : Menu Description Tables
Me
n
u
‹ Note
When the DS.GAIN function is active, the shutter mode is
set to OFF.
The ____ in the Adjustable Range column indicates the
preset mode.
USER SW GAIN
Items/
Data Saved
Adjustable
Range
Remarks
S.GAIN
30 dB
¢
• Select whether or not to enable 30dB for
SUPER GAIN.
¢: Enable.
• : Disable.
– C U F R
36 dB ¢
• Select whether or not to enable 36dB for
SUPER GAIN.
¢: Enable.
• : Disable.
– C U F R
42 dB ¢
• Select whether or not to enable 42dB for
SUPER GAIN.
¢: Enable.
• : Disable.
– C U F R
48 dB ¢
• Select whether or not to enable 48dB for
SUPER GAIN.
¢: Enable.
• : Disable.
– C U F R
DS.GAIN
6 dB :
¢
• Select whether or not to enable 6 dB : for
DS.GAIN.
¢: Enable.
• : Disable.
– C U F R
10 dB : ¢
• Select whether or not to enable 10 dB :
for DS.GAIN.
¢: Enable.
• : Disable.
– C U F R
12 dB : ¢
• Select whether or not to enable 12 dB :
for DS.GAIN.
¢: Enable.
• : Disable.
– C U F R
15 dB : ¢
• Select whether or not to enable 15 dB :
for DS.GAIN.
¢: Enable.
• : Disable.
– C U F R
20 dB : ¢
• Select whether or not to enable 20 dB :
for DS.GAIN.
¢: Enable.
• : Disable.
– C U F R
LENS/IRIS
Items/
Data Saved
Adjustable
Range
Remarks
A.IRIS LEVEL 000
:
045
:
100
Set the target value for auto iris.
– C U F R
A.IRIS PEAK/
AVE 000
:
030
:
100
Determine the peak-to-standard ratio for
the auto iris.
A larger value sets the auto iris to
respond to the peak in the IRIS
detection window, while a smaller value
sets it to respond to the average value in
the window.
– C U F R
A.IRIS
WINDOW NORM1
NORM2
CENTR Select the auto iris detection window.
NORM1: The window closer to the center
of the screen.
NORM2: The window closer to bottom of
the screen.
CENTR: The spot window in the center of
the screen.
– C U F R
S.IRIS LEVEL 000
:
080
:
100
Set the target value for the super iris
(Backlight correction function).
– C U F R
IRIS GAIN CAM
LENS Select which unit controls IRIS GAIN.
‹ Note
Lenses with an extender, such as a2,
a0.8 sold before FUJINON DIGI
POWER, perform IRIS compensation
while enabling the extender. Therefore, if
this setting is switched to CAM, the
camera’s iris control will not operate
properly.
– C U F R
IRIS GAIN
VALUE 01
:
10
:
20
Set the adjustable value for IRIS GAIN.
This setting is effective when CAM is
selected for IRIS GAIN.
– C U F R
