151 Menu : Menu Configuration
Me
n
u
About Menu Description Tables
USER MENU
USER MENU SELECT
SYSTEM SETTING
PAINT
CAM OPERATION
SYSTEM MODE
OPTION MODE
REC FUNCTION
OUTPUT SEL
GENLOCK
RGB BLACK CONTROL
LOW SETTING
MID SETTING
CAMERA ID
SHUTTER SPEED
SHUTTER SELECT
USER SW
SW MODE
WHITE BALANCE MODE
LENS/IRIS
USER SW GAIN
MATRIX
COLOR CORRECTION
SYSTEM SETTING(USER)
PAINT(USER)
VF(USER)
CAM OPE(USER)
FILE(USER)
MAINTENANCE(USER)
MAIN OPE(USER)
SKIN TONE DTL
KNEE/LEVEL
HIGH SETTING
ADDITIONAL DTL
GAMMA
CAMERA SETTING
VF VF DISPLAY
VF MARKER
VF USER BOX
VF INDICATOR1
VF INDICATOR2
MODE CHECK IND
FILE SD CARD READ/WRITE
SD CARD R/W SELECT
LENS FILE
SCENE
INITIALIZE
MAINTENANCE SYSTEM CHECK
LENS ADJ
BLACK SHADING
WHITE SHADING
MENU
MAIN MENU
OPTION MENU
OPTION
! LED
MAIN OPERATION
BATTERY SETTING2
MIC/AUDIO 1
BATTERY/P2CARD
BATTERY SETTING1
UMID SET/INFO
MIC/AUDIO 2
TC/UB
LCD MONITOR
DIAGNOSTIC1
DIAGNOSTIC2
HOURS METER
DOWNCON SETTING
1394 SETTING
RB GAIN CONTROL
LENS FILE CARD R/W
LENS FILE ADJ
Opening the Menus
USER MENU:
Displayed when the MENU
button is pressed.
MAIN MENU:
Displayed when the MENU
button is pressed for at least 3
seconds.
OPTION MENU:
Displayed when the MENU
button is pressed while pressing
the LIGHT button.
‹ Notes
z The items highlighted in grey cannot be selected by .
z The underlined items can only be selected as one whole page (with all sub-items). Individual sub-items cannot be
selected separately.
The following letters indicate whether the modified menu
data is saved to or read out from the memory.
The – indicates that the data cannot be saved or read.
S = Can be saved and read as scene data file.
C = Can be saved or read using CARD READ/WRITED.
U = Can be saved and read as user data.
Please refer to [SCENE] (page 185) and [INITIALIZE]
(page 185).
F = Can be read using READ FACTORY DATA.
Please refer to [INITIALIZE] (page 185).
R = Can be saved using RC DATA SAVE.
Please refer to [Connection of the remote control unit
(AJ-RC10G)
] (page 107).
Items/
Data Saved
Adjustable
Range
Remarks
REC SIGNAL CAM
VIDEO
1394
SDI Select video input signals.
CAM: Record the signal from the
camera
VIDEO:Record the signal from the
GENLOCK IN connector (In SD
mode only
1394: Record the signal from the 1394
input connector
SDI: Records input to the SD IN
connector (optional). – C U F R
This section shows the
adjustable range of the
set value, and available
options for this item. About the settings available for
this item.
Menu
Menu Configuration
