181 Menu : Menu Description Tables
Me
n
u
‹ Note
The frequency characteristics when the micro cut filter is applied are
200 Hz to 10 kHz.
The ____ in the Adjustable Range column indicates the
preset mode.
MIC/AUDIO1
Items/
Data Saved
Adjustable
Range
Remarks
FRONT VR
CH1 OFF
FRONT
W.L.
REAR
ALL Select whether or not to enable the
FRONT AUDIO LEVEL control for the
signal selected as the input signal to
AUDIO CH1.
OFF:
Disabled for any input selected.
Recording level does not change
by turning the volume control.
FRONT: Only enabled when FRONT is
selected.
W.L.: Only enabled when WIRELESS
is selected.
REAR: Only enabled when REAR is
selected.
ALL: Enabled for any input selected.
– C U F –
FRONT VR
CH2 OFF
FRONT
W.L.
REAR
ALL Select whether or not to enable the
FRONT AUDIO LEVEL control for the
signal selected as an input signal to
AUDIO CH2.
OFF:
Disabled for any input selected.
Recording level does not change
by turning the volume control.
FRONT: Only enabled when FRONT is
selected.
W.L.: Only enabled when WIRELESS
is selected.
REAR: Only enabled when REAR is
selected.
ALL: Enabled for any input selected.
– C U F –
MIC LOWCUT
CH1 OFF
FRONT
W.L.
REAR Select the microphone low cut filter for
Input Channel 1.
OFF:
The microphone low cut filter is
disabled for any input.
FRONT: The microphone low cut filter is
enabled when the front
microphone is selected.
W.L.: The microphone low cut filter is
enabled only when the wireless
microphone is selected.
REAR: The microphone low cut filter is
enabled only when the rear
microphone is selected.
– C U F –
MIC LOWCUT
CH2 OFF
FRONT
W.L.
REAR Select the microphone low cut filter for
Input Channel 2.
OFF:
The microphone low cut filter is
disabled for any input.
FRONT: The microphone low cut filter is
enabled when the front
microphone is selected.
W.L.: The microphone low cut filter is
enabled only when the wireless
microphone is selected.
REAR: The microphone low cut filter is
enabled only when the rear
microphone is selected.
– C U F –
MIC LOWCUT
CH3 OFF
FRONT
W.L.
REAR Select the microphone low cut filter for
Input Channel 3.
OFF:
The microphone low cut filter is
disabled for any input.
FRONT: The microphone low cut filter is
enabled when the front
microphone is selected.
W.L.: The microphone low cut filter is
enabled only when the wireless
microphone is selected.
REAR: The microphone low cut filter is
enabled only when the rear
microphone is selected.
– C U F –
Items/
Data Saved
Adjustable
Range
Remarks
MIC LOWCUT
CH4 OFF
FRONT
W.L.
REAR Select the microphone low cut filter for
Input Channel 4.
OFF:
The microphone low cut filter is
disabled for any input.
FRONT: The microphone low cut filter is
enabled when the front
microphone is selected.
W.L.: The microphone low cut filter is
enabled only when the wireless
microphone is selected.
REAR: The microphone low cut filter is
enabled only when the rear
microphone is selected.
– C U F –
LIMITER CH1 ON
OFF
Select the limiter.
The limiter is enabled when AUDIO
SELECT CH1 switch is set to MAN.
– C U F –
LIMITER CH2 ON
OFF
Select the limiter.
The limiter is enabled when AUDIO
SELECT CH2 switch is set to MAN.
– C U F –
AUTO LEVEL
CH3 ON
OFF Select the level setting method.
For more information, see [CH3 and
CH4 Recording Levels
] (page 54)
– C U F –
AUTO LEVEL
CH4 ON
OFF Select the level setting method.
For more information, see [CH3 and
CH4 Recording Levels
] (page 54)
– C U F –
25M REC CH
SEL 2CH
4CH Select the audio channels to be
recorded in the DVCPRO and DV
formats.
2CH: Only recorded in CH1 and CH2.
4CH: Recorded in all channels from CH1
to CH4.
– C U F –
TEST TONE OFF
NORMAL
ALWAYS
CHSEL Select the test signal.
OFF:
Disable test tone output.
NORMAL: Test tone signals are output to
all of Channels 1 - 4 when the
OUTPUT/AUTO KNEE
selector switch has been
switched to BARS and CH1 of
the AUDIO IN switch has been
switched to FRONT.
ALWAYS: Test tone signals are always
output to all of Channels 1 - 4
when the OUTPUT/AUTO
KNEE selector switch has
been switched to BARS.
CHSEL: Output test tone to the
channels where the AUDIO IN
switch CH1 or CH2 is set to
FRONT when OUTPUT/AUTO
KNEE selector switch is set to
BARS. The test tone is not
output to CH3 and CH4.
– C U F –
