164 Menu : Menu Description Tables
‹ Note
The items indicated by „ are the setting items for PAINT
MENU SW( „ ) R/W in the
screen. The items without „ are the setting items for
PAINT MENU LEVEL R/W.
Please refer to [
SD CARD R/W SELECT ] (page 184) for
more information.
The ____ in the Adjustable Range column indicates the
preset mode.
MID SETTING
Items/
Data Saved
Adjustable
Range
Remarks
„MASTER
GAIN –3dB
6dB
30dB
Select the master gain from –3, 0, 3, 6,
9, 12, 15, 18, 21, 24, 27, or 30dB.
S C U F –
H.DTL LEVEL 00
08
63
For performing the horizontal detail
correction level setting.
S C U F –
V.DTL LEVEL 00
18
31
For performing the vertical detail
correction level setting.
S C U F –
DTL CORING 00
02
15
For performing the noise elimination
level setting for detail.
S C U F –
H.DTL FREQ. 00
18
31
For performing the horizontal detail
frequency selection.
S C U F –
LEVEL
DEPEND. 0
1
5
For setting the LEVEL DEPEND.
When the Y-detail is emphasized,
details of dark sections are
compressed.
If the numerical value is larger, details of
bright sections are also compressed.
S C U F –
MASTER
GAMMA 0.30
0.45
0.75
For setting the master gamma. (0.01
step)
S C U F –
BLACK
GAMMA –3
:
OFF
:
+3
For setting the gamma curve for the
dark portion.
–3 to –1:
The dark portion is compressed.
OFF:
Standard state
+1 to +3:
The dark portion is extended.
S C U F –
„MATRIX
TABLE OFF
A
B For selecting the color correction table
for the linear matrix.
S C U F –
„COLOR
CORRECT ON
OFF For switching ON/OFF of the 12-axis
independent color correction.
S C U F –
HIGH SETTING
Items/
Data Saved
Adjustable
Range
Remarks
„MASTER
GAIN –3dB
12dB
30dB
Select the master gain from –3, 0, 3, 6,
9, 12, 15, 18, 21, 24, 27, or 30dB.
S C U F –
H.DTL LEVEL 00
06
63
For performing the horizontal detail
correction level setting.
S C U F –
V.DTL LEVEL 00
16
31
For performing the vertical detail
correction level setting.
S C U F –
DTL CORING 00
03
15
For performing the noise elimination
level setting for detail.
S C U F –
H.DTL FREQ. 00
18
31
For performing the horizontal detail
frequency selection.
S C U F –
LEVEL
DEPEND. 0
3
5
For setting the LEVEL DEPEND.
When the Y-detail is emphasized,
details of dark sections are
compressed.
If the numerical value is larger, details of
bright sections are also compressed.
S C U F –
MASTER
GAMMA 0.30
0.55
0.75
For setting the master gamma. (0.01
step)
S C U F –
BLACK
GAMMA –3
:
OFF
:
+3
For setting the gamma curve for the
dark portion.
–3 to –1:
The dark portion is compressed.
OFF:
Standard state
+1 to +3:
The dark portion is extended.
S C U F –
„MATRIX
TABLE OFF
A
B For selecting the color correction table
for the linear matrix.
S C U F –
„COLOR
CORRECT ON
OFF For switching ON/OFF of the 12-axis
independent color correction.
S C U F –
