Panasonic AJ-HPX2000 User Manual

Page 158

158

Menu : Menu Description Tables

Note

The screen is displayed when
SYSTEM MODE is set to 1080-59.94i, 1080-50i, 720-
59.94P and 720-60P (HD mode).

The ____ in the Adjustable Range column indicates the
preset mode.

OUTPUT SEL

Items/

Data Saved

Adjustable

Range

Remarks

OUTPUT ITEM MENU ONLY

TC
STATUS

Set the character contents
superimposed onto the output signals
for the VIDEO OUT connector (Analog
or SDI) and MON OUT connector.
MENU ONLY:

Displays only when the menu
characters are superimposed. No
display appears when other characters
are superimposed.

TC:Display the time code. (Displays the

menu when menu characters are
superimposed.)

Note

The TC display position moves up
and down depending on the camera
ID position.

STATUS:

Display the same characters
superimposed on the VF signal.
(Displays the menu when menu
characters are superimposed.)

– C U F –

MONITOR
OUT

VBS
VF
Y

Select the output signal on the MON OUT
connector.
VBS: Output a regular composite signal.
VF: Output a VF Y signal. The status

display is also superimposed.

Output a component Y signal.

Note

The VBS signal is output in playback
mode.

– C U F –

MONITOR
OUT CHAR

ON
OFF

Select whether or not to superimpose
characters on the MON OUT connector
signal independently of the camera’s
VIDEO OUT CHARACTER switch. (The
character content is the same as the
video output signal.)
ON: Enable superimpose.
OFF: Disable superimpose.

– C U F –

LCD MON
CHAR

ON
OFF

Select whether or not to superimpose
characters on the LCD monitor. (The
character content is the same as the
video output signal.)
ON: Enable superimpose.

(Not interlocked with the VIDEO
OUT CHARACTER switch.)

OFF: Disable superimpose.

(Not interlocked with the VIDEO
OUT CHARACTER switch.)

– C U F –

VF MODE

MEM
CAM

When the REC SIGNAL menu option on
the SYSTEM MODE screen is set to
CAM, select the image to display in the
viewfinder.
MEM: Display the playback image in the

playback mode.

CAM: Always display the camera image.

– C U F –

THUMBNAIL
OUT

ON
OFF

Select whether or not to output clip
thumbnails displayed on the LCD
monitor to the video output and monitor
output signals.
ON: Enable output.
OFF: Disable output.

Note

HD SDI signals are being output from
the VIDEO OUT connector, thumbnails
are not output.

– C U F –

DOWNCON SETTING

Items/

Data Saved

Adjustable

Range

Remarks

DOWNCON
MODE

SQUEEZ
LT-BOX
S-CROP

For setting the mode of the down
converter output signals.

– C U F R

DETAIL

ON
OFF

For setting the detail function for the
down converter output signals ON/OFF.
The down converter output signals
contain detailed components that are
set during HD signal processing. In this
setting, these signals overlap the
detailed components dedicated to the
down converter outputs.
Even if this setting is turned off, it is
impossible to turn off the detailed
components set during HD signal
processing.

– C U F R

H.DTL LEVEL 00

For setting the horizontal detail
correction level for the down converter
output signals.

– C U F R

V.DTL LEVEL 00

For setting the vertical detail correction
level for the down converter output
signals.

– C U F R

DTL CORING 00

01
:
15

For setting the noise elimination level of
the details.

– C U F R

H.DTL FREQ. 1

For selecting the horizontal detail
frequencies.
1: 2.5 MHz 4: 4 MHz
2: 3 MHz

5: 4.5 MHz

3: 3.5 MHZ

– C U F R

2D LPF

ON
OFF

For setting the 2-D low path filter
reducing cross colors.
ON:

Cross colors are reduced.

OFF: Cross colors are not reduced.

– C U F R

SETUP

0%
7.5%

For setting the setup level for the down
converter output signals.

Only for 1080-59.94i or 720-59.94P

Note

When the system frequency is set to 50
Hz, the setup level will be 0%.

– C U F R
