Table J. Equipment Weight
Weight Kg (lbs.)
Powerware Model
Shipping Installed Point Loading
9335 – 80 kVA 360 (792) 333 (733) 4 at 83 (183)
9335 – 120 kVA 367 (807) 340 (748) 4 at 85 (187)
5. The clearances required around the UPS system are shown in Table K.
Table K. System Clearances
From Front of Cabinet 36 inches working space
From Back of Cabinet 30 inches working space
From Right or Left side of Cabinet ~0 inches clearance
6. The basic environmental requirements for operation of the UPS system are:
Ambient Temperature Range: 0 – 40˚C. (32 – 104˚F.)
Recommended Operating Range: 20 – 25˚C. (68 – 77˚F.)
Maximum Relative Humidity:
95% (non-condensing)
The UPS ventilation requirements for heat removal are shown in Table L.
Table L. Air Conditioning or Ventilation Requirements
During Full Load Operation
Powerware 9335 80kVA and 120 kVA
Powerware Model Input/Output Voltage Heat Rejection
BTU/hr x 1000/hr (g-cal/hr)
9335 – 80 kVA 480/480 linear load pf = 0.8 14.0 (3.5)
9335 – 120 kVA 480/480 linear load pf = 0.8 20.8 (5.2)
9335 – 80 kVA 480/480 linear load pf = 1.0 16.4 (4.2)
9335 – 120 kVA 480/480 linear load pf = 1.0 24.6 (3.1)
9335 – 80 kVA 480/480 100% non-linear load 17.7 (4.4)
9335 – 120 kVA 480/480 100% non-linear load 26.6 (6.6)
Powerware 9335 (80 kVA and 120 kVA) Installation and Operation A-9
164201396 REV A 07/11/2003
