7. Terminals are UL rated at 90

o

C. Refer to Table C for power cable terminations and

Table D for conduit requirements. Figure A–1 shows the location of power cable
terminals inside the UPS.

Table C. UPS Cabinet Power Cable Terminations for Powerware 9335 (80 kVA & 120 kVA)

Terminal
Function

Terminal

Function

Size of Pressure
Termination

Vendor Tightening

Torque

N-M (lb-in.)

Int.Hex
Size (in.)

A

Phase A

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

B

Phase B

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

C

Phase C

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

AC Input to
UPS
Rectifier

N

Neutral

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

A

Phase A

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

B

Phase B

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

C

Phase C

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

AC Input to
Bypass
(Dual
Input)

N

Neutral

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

A

Phase A

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

B

Phase B

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

C

Phase C

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

AC Output
to Critical
Load

N

Neutral

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

+

Battery(+)

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

N

Mid-point

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

DC Input
from
Battery to
UPS

-

Battery (

-

)

1 - #6-250 kcmils Cooper

42.4 (375)

3/8

Customer
Ground

Protective
Ground

Protective
Ground

4 - #6-250 kcmils Cooper

As Required

8. Per NEC article 300-20 (a), all three-phase conductors must be run in the same

conduit. Neutral and ground must be run in the same conduit as the phase
conductors.

9. Conduit is sized to accommodate one neutral conductor the same size as the phase

conductor and one protective ground wire of the same size.

10. Conduit sizes were chosen from NEC Table C1, type letters RHH, RHW, RHW-2,

TW, THW, THHW, and THW-2.

Table D. Power Cable Conduit Requirements Powerware 9335 (80 kVA & 120 kVA)
Powerware
Product Model

Terminal Wires

in

Conduit

Minimum Conduit
Size (in.)

No. of
Conduits

Rectifier Input (A,B,C,N,G)

5 2.0

inches 1

Bypass Input (A,B,C,N,G)

5 2.0

inches 1

Ext. Battery Source (+,N,-,G)

4 2.5

inches 1


9335–80 kVA

Output (A,B,C,N,G)

5 2.0

inches 1

Rectifier Input (A,B,C,N,G)

5 2.5

inches 1

Bypass Input (A,B,C,N,G)

5 2.5

inches 1

Ext. Battery Source (+,N,-,G)

4 2.5

inches 1


9335–120 kVA

Output (A,B,C,N,G)

5 2.5

inches 1

A-4

Powerware 9335 (80 kVA and 120 kVA) Installation and Operation

164201396 REV A 07/11/2003
