7-6 Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV A 071103
7.3.3 Main Menu Screen
DESCRIPTION
LCD DISPLAY
• Logging Control. A log of the last 64 events is
stored in the Power Management Display.
• Menu Measurements allow monitoring voltages,
power, frequencies, current, battery run time,
and other information.
• Command Menu enables performance of
“Load to Inverter”, “Load to Bypass”, and
battery test functions.
• UPS Data Menu shows UPS serial number,
date of manufacture, current time & date.
• Set-Up Menu allows user to set Date/Time,
automatic battery test and gen-set mode
• Set-Up Menu for service allows trained.
service personnel to troubleshoot and
adjust system parameters.
7.3.4 Event Log Screen
DESCRIPTION LCD DISPLAY
• Logging Control (sample screen)
• A log of the last 64 events is stored
and presented under the Event Log.
• All events and alarms are displayed
with their date and time of occurrence.
7.3.5 Measurements Screen
DESCRIPTION LCD DISPLAY
• Battery Runtime remaining (in minutes)
• UPS Output Frequency
• Bypass Frequency
EVENT LOG
MEASUREMENTS
COMMANDS
UPS DATA
SET-UP USER
SET-UP SERVICE
BATT. RUN TIME (MIN)
0.0
02-27-02 17-03-30
LOAD TO INV.
02-27-02 17-03-30
LOAD TO BYP.
02-27-02 17-03-30
LOAD OFF
OUTPUT FREQUENCY (HZ)
60.00
BYPASS FREQUENCY (HZ)
60.00
