Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-5
164201396 REV. A 071103
7.3.2 LCD Display Structure and Navigation
The menu structure is shown in Figure 7–3, below. Navigation through the menu is
accomplished by using the “ENTER” pushbutton to go to the menu level, or to activate
an action, then using the “UP” or “DOWN” arrows to select a specific function within
each menu category. The “RESET” pushbutton will immediately return to the highest
screen.
Figure 7–3. LCD Screen Navigation Chart
LOAD
PROTECTED
LOAD
NOT PROTECTED
LOAD OFF
SUPPLY FAIL
EVENT LOG
MEASUREMENTS
COMMANDS
UPS DATA
SET-UP USER
•
HH-MM-SS
LOAD TO INV.
02-27-02 HH-MM-SS
LOAD TO BYP.
02-27-02 HH-MM-SS
LOAD OFF
LOAD TO INVERTER
LOAD TO
BYPASS
PERFORM
BATT.TEST
UPS SERIAL NUMBER
M-
DATE OF MANUFACTURE
DATE TIME
PRESS ENTER
PRESS RESET, RETURNS TO TOP LEVEL
BATT. RUN TIME (MIN)
0.0
OUTPUT FREQUENCY (HZ)
60.00
BYPASS FREQUENCY (HZ)
60.00
BATTERY VOLTAGE (V)
+ 240
-240
BATT. CHARGE CUR. (A)
+ 0.0 -0.0
DISCHARGE CURRENT (A)
0
RECTIFIER VOLTAGE (V)
000 000 000
OUTPUT VOLTAGE (V)
000 000 000
BYPASS VOLTAGE (V)
000 000 000
OUTPUT CURRENT (A)
00 00 00
APPARENT POWER ((KVA)
00 00 00
REACTIVE POWER (KVAR)
00 00 00
ACTIVE POWER (kW)
00 00 00
BATT. CAPACITY (%)
00
OUTPUT POWER (%)
00.0 00.0 00.0
