ix Powerware 9335 (80 kVA and 120 kVA) Installation and Operation
164201396 REV. A 071103
Basic System Configurations
These basic UPS system configurations are possible:
•
Single Cabinet UPS with External Battery Cabinet, Single Utility Feed
•
Single Cabinet UPS with External Battery Cabinet, Dual Utility Feed
You can enhance any of these system configurations by adding optional accessories,
such as Remote Emergency Power Off (EPO) control and X–Slot communications
connectivity features.
Using This Manual
Your UPS functions automatically and requires very little attention during normal
operation. However, you should read and understand the procedures described in this
manual to ensure trouble-free operation. In particular, you should be thoroughly familiar
with the Remote Emergency Power Off procedure described in Chapter 4 of this
manual.
The information in this manual is divided into the sections and chapters listed. The
system you are installing dictates which parts of the manual you should read. Everyone
should read the Introduction, Chapters 1, 2, 7, and 8.
Introduction
The introduction provides a brief description of the UPS system, a description of the
content of each chapter, safety, and text conventions used in the manual and reference
information.
Section I – Installation
•
Chapter 1 – Getting Started – tells you how to prepare your site for the
installation of your UPS system. It discusses equipment environmental
requirements, inspecting, and unpacking cabinets.
•
Chapter 2 – Installing the UPS System – describes how to install the UPS
cabinets and optional equipment.
•
Chapter 3 – Installing and Connecting Batteries – provides battery safety,
installation and connection information.
•
Chapter 4 – Installing a Remote EPO Control – contains information for
installing the optional Remote Emergency Power Off (REPO) control.
