Powerware 9335 (80 kVA and120 kVA) Installation and Operation 7-7
164201396 REV. A 071103
• Battery Voltage
• Battery Charger Current
• Discharge Current
• Rectifier Voltage (all three phases)
• Bypass Voltage (all three phases)
• Output Voltage (all three phases)
• Output Current (all three phases)
• Active Output Power (all three phases)
• Reactive Output Power (all three phases)
• Apparent Output Power (all three phases)
• Output Power (%, all three phases)
• Battery Capacity remaining
7.3.6 Commands Screen
DESCRIPTION LCD DISPLAY
• Transfer Load to Inverter
• Transfer Load to Bypass
• Battery Test
BATTERY VOLTAGE (V)
+240 -240
BATT. CHARGE CUR. (A)
+ 0.0 - 0.0
DISCHARGE CURRENT (A)
+ 0.0 - 0.0
RECTIFIER VOLTAGE (V)
0
0 0
BYPASS VOLTAGE (V)
0
0 0
OUTPUT VOLTAGE (V)
0
0 0
OUTPUT CURRENT (A)
0
0 0
ACTIVE POWER (kW)
0
0 0
REACTIVE POWER (kVAR)
0
0 0
APPARENT POWER (KVA)
0
0 0
OUTPUT POWER (%)
0%
0% 0%
BATT. CAPACITY (%)
0%
LOAD TO INVERTER
LOAD TO BYPASS
PERFORM BATT. TEST
