Promise Array Management
40
RAID System Icon
The RAID System icon represents the FastTrak SX4000 series and S150
SX4 PCI cards (right). There are two commands for this item:
• Screen refresh
• Rename the RAID Machine icon
Controller Icon
Right-click on the Controller icon to access the following commands:
• Read Events in the Event Viewer
• Clear Events from the Event Viewer
• Read Bad Sector Table
• Toggle the Beeper on and off
• Create a New Array
• Refresh the screen
• Rename the Controller icon
Channel Icon
The Channel icon represents an individual channel on the FastTrak PCI
card. There are two commands for this item.
• Refresh the screen
• Rename the Controller icon
Disk Icon
Right-click on the Disk icon of an unassigned drive or the Disk icon of an
assigned drive to access the following commands:
• Refresh the screen
• Rename the Controller icon
