Psion Teklogix 7530 G2 Hand-Held Computer User Manual

151

Chapter 5: Configuration

Non-Decoded Scanners

Prefix/Suffix

Prefix Char

This character, if non-zero, is added before a successfully decoded bar code. Press
the key you want to insert in the dialog box attached to this parameter. The
ASCII/Unicode key value of the keypress is displayed.
Pressing the [ESC] key in this dialog box resets the data to zero.

Suffix Char

This character, if non-zero, is added after a successfully decoded bar code. Press the
key you want to insert in the dialog box attached to this parameter. The
ASCII/Unicode key value of the keypress is displayed.
Pressing the [ESC] key in this dialog box resets the data to zero.

Strip Leading

This parameter determines the number of characters that will be removed from the
beginning of the bar code before the prefix character is added.
Note: The appended character is treated as any other keyboard character. For

example, if [BKSP] is pressed, the usual action for that key is performed.
If your hand-held is operating with the Psion Teklogix ANSI emulation
application, the hand-held transmits the escape sequence associated with
the function immediately after the bar code data.

Strip Trailing

The value entered in this parameter determines the number of characters that will be
removed from the end of the bar code before the suffix character is added.

5.11.2.5 EAN 8

Enabled

Set this parameter to on to enable “EAN 8” or off to disable it.

Include Check

If this parameter is enabled, the check digit is included with the decoded bar
code data.
