DSL Ports 42
Model 3224 G.SHDSL IpDSLAM User Manual B • Specifications
DSL Ports
24 G.SHDSL ports presented on an RJ-21X 50-pin connector, each supporting data rates of nx64 (192 kbps -
4.6 Mbps)
Ethernet Ports
Dual 10/100BaseT (RJ-45 connector); auto-negotiating; half or full duplex operation
WAN Clocking
Internal, Network Receive Recover (from expansion port), External BITS via Form-C relay contacts
Front Panel Indicators
LEDs for power, CPU, system, Ethernet, External clock, test mode, DSL, and Up-link Egress module
Power Supplies
Hot swap, dual-redundant AC or DC; AC power: 115 or 230 VAC (50/60 Hz); DC power: -36 to -72 VDC
Management Service
HTTP, SNMP, Telnet Server, RS-232 Console Port, SYSLOG Client, Software upgrade via FTP or TFTP
Alarm Reporting
Configurable alarms; Remote SNMP Traps; Front Panel LEDs; Form-C relay contacts
Environment
Operating temperature: 0 to 40°C (32 to 104°F); Humidity: 5 - 90% non-condensing
Dimensions
48.25 W x 32.00 D x 4.44 H cm (19.00 W x 12.60 D x 1.75 H inches) - 1U by 19 in. wide
