2. Configuring the desired IP address 27
Model 3224 G.SHDSL IpDSLAM User Manual 3 • Initial configuration
Factory-default IP settings
The factory default configuration for the Ethernet interface IP addresses and network masks are listed in table 3 .
Both Ethernet interfaces are activated upon power-up.
If these addresses match with those of your network, go to section “3. Connecting the IpDSLAM to the net-
work” on page 28. Otherwise, refer to the following sections to change the addresses and network masks.
Login
To access the IpDSLAM, start the ssh application. Type the default IP address for the router into the address
field: 192.168.200.10. Accessing your IpDSLAM via an ssh session displays the login screen. Type the factory
default login: admin and password: .
login: admin
password:
Trinity#
Changing the IP address
You can set your IP address and network mask for the interface ETH 0 (LAN). Within this example a network
192.168.1.1/24 address is assumed. The IP address in this example is set to 192.168.1.1 (you should set this
with the IP address given to you by your network provider).
Trinity# configure
Trinity[config]# interface ethernet eth0
Trinity[eth-eth0]# ip address 192.168.1.1 netmask 255.255.255.0
Trinity[eth-eth0]# no ip address 192.168.200.10
Note If you logged into the IpDSLAM with the IP address 192.168.200.10, you
will need to reset your PC IP address to an address in the same network such
as 192.168.1.5 and log back into the IpDSLAM. Connectivity via the ssh
session will be lost once the 192.168.200.10 address is removed.
Saving the IP address
To save the unit’s IP address, login to the unit using admin, then use the following set of commands:.
Trinity# [eth-eth0]# end
Trinity# copy running-config startup-config
Trinity#
Table 3. Factory default IP address and network mask configuration
IP Address Network Mask
LAN interface Ethernet 0 (ETH 0) 192.168.200.10 255.255.255.0
LAN interface Ethernet 0 (ETH 0) DHCP DHCP
LAN interface Ethernet 1 (ETH 1) - -
