3. Connecting the IpDSLAM to the network 28
Model 3224 G.SHDSL IpDSLAM User Manual 3 • Initial configuration
3. Connecting the IpDSLAM to the network
In general, the IpDSLAM will connect to the network via the LAN (ETH 0) port. This enables the IpDSLAM
to offer routing services to the PC hosts on LAN (ETH 1) port. The IpDSLAM is equipped with Auto-MDX
Ethernet ports, so you can use straight-through or crossover cables for host or hub/switch connections.
You can check the connection with the ping command from the IpDSLAM to another host on the network:
Trinity#ping . If the WAN address is not set to DHCP, to ping a device outside
your local LAN you must first configure the default gateway.
Note For more detailed configuration instructions, see the TrinityAE Administra-
tor’s Reference Guide available online at www.patton.com/manuals/Trinity-
arg.pdf.
The interconnecting cables shall be acceptable for external use
and shall be rated for the proper application with respect to volt-
age, current, anticipated temperature, flammability, and
mechanical serviceability.
CAUTION
