Model 3224 G.SHDSL IpDSLAM User Manual 4 • Operation and shutdown
Introduction
This chapter describes how to start or power-down the IpDSLAM.
Activating the IpDSLAM
Once the IpDSLAM has been installed, no operator action is required under normal conditions; the
IpDSLAM is designed for unattended operation. The IpDSLAM does not have a power switch. When either
power supply is connected to power, the IpDSLAM will immediately begin its boot-up cycle. However, both
power supplies must be connected to power for the redundancy feature to work.
When power is applied to the IpDSLAM the following should occur:
1. The POWER LED illuminates.
2. The Link 1 Frame LED illuminates, indicating that the IpDSLAM is synchronizing with the T1/E1/PRI
signal.
3. After 5 seconds, the Link A Error LED flashes, indicating that the IpDSLAM is satisfied with the quality of
the T1/E1/PRI signal.
4. After 10 seconds, the Link A Error LED extinguishes, indicating that the IpDSLAM is satisfied with the
network signal and that the link is ready for use.
5. There are two LEDs on each IpDSLAM 10/100 Ethernet port: a green LED that indicates line speed, and
a yellow LED that indicates link status and activity.
The yellow LED is either flashing yellow (meaning that packets are being received at the Ethernet port) or
solid yellow (meaning that the link is valid but no packets are being received).
The green LED is either lit (indicating 100 Mbps operation) or off (indicating 10 Mbps operation).
Note The green LED reflects the speed of the last valid Ethernet
connection.
The IpDSLAM is operational.
De-activating the IpDSLAM
Perform the following procedure to deactivate the IpDSLAM.
1. Disconnect the male ends of both power cords from the power distribution strip or to a wall outlet.
2. Verify that the POWER LED extinguishes.
