Patton electronic CopperLink 2160 Series - Manual (Page 59)

Administration Options 59
Model 2160 Series Getting Started Guide 4 • Web configuration
User Profiles
For better security, change the Supervisor ID and Supervisor Password for the Model 2160. If you don't set
them, all users will be able to access the Model 2160 using the default Supervisor ID and Supervisor Password
,which is root.
You can authorize five legal users to access the Model 2160 via telnet or console only. There are two UI modes,
menu driven mode and command mode to configure the Model 2160. The default user name and Password
are admin. There are two UI modes, the WMI and the Telnet/Console mode to set up the Model 2160.
Figure 35. Model 2160 configuration modes
Remote Management Hosts
The Remote Management Host section of the Security Administration page enables you to set up the legal IP
addresses from which authorized persons can configure the Model 2160. This is the most secure way for the
network administrator to set up the legal address of configuration.
Figure 36. Remote Management Host section
Telnet Console Mode Web Browser Mode
User Name
Password
Exit
Supervisor Password
All functions are available
Only available functions:
Ping, View Status, Configuration
Supervisor ID
Supervisor Password
Logout
All functions are available
