Advanced Configuration Options 54
Model 2160 Series Getting Started Guide 4 • Web configuration
The standardized DiffServ field of the packet is marked with a value so that the packet receives a particular for-
warding treatment at each network node. RFC 2597 defines the assured forwarding (AF) classes. There are
four AF classes, AF1x through AF4x. Within each class, there are three drop probabilities. Depending on a
given network's policy, packets can be selected for a PHB based on required throughput, delay, jitter, loss, or
according to priority of access to network services. Classes 1 through 4 are referred to as AF classes.
Table 12 illustrates the DSCP coding for specifying the AF class with the probability. Bits 0, 1, and 2 define
the class; bits 3 and 4 specify the drop probability; bit 5 is always 0.
Table 11. Bits in the DSCP field
Bit 0 Bit 1 Bit 2 Precedence Usage
1 1 1 7 Stays the same (link layer and routing protocol keep alive)
1 1 0 6 Stays the same(used for IP routing Protocols)
1 0 1 5 Express Forwarding (EF)
1 0 0 4 Class 4
0 1 1 3 Class 3
0 1 0 2 Class 2
0 0 1 1 Class 1
0 0 0 0 Best effort
Bit 3 Bit 4 Bit 5 Usage Meaning
0 – – Delay Normal
1 – – Delay Low
– 0 – Throughput Normal
– 1 – Throughput High
– – 0 Reliability Normal
– – 1 Reliability High
Table 12. DSCP Coding
Class 1 Class 2 Class 3 Class 4
Low Drop 001010
AF11
DSCP 10 010010
AF21
DSCP 18 011010
AF31
DSCP 26 100010
AF41
DSCP 34
Medium Drop 001100
AF12
DSCP 12 010100
AF22
DSCP 20 011100
AF32
DSCP 28 100100
AF42
DSCP 36
High Drop 001110
AF13
DSCP 14 010110
AF23
DSCP 22 011110
AF33
DSCP 30 100110
AF43
DSCP 38
