DualFlow DSU Configuration Worksheet (2 of 2)

DBM Port (232)

Value

DTE Port

232, V.35

}

RTS Cntrl

FrcOn, DTE

CTS Cntrl

Std, =RTS, FrcOn

AntiStream

(Chang)

Disab (1 to 100 sec)

LSD Lead

Std, FrcOn

DSR FrcOn

Enab, Disab

DSR on Tst

Enab, Disab

RespondRDL

Enab, Disab

RL by DTE

Enab, Disab

Bilat Lpbk

Enab, Disab

Ext Leads

ExtLd, Rate, RPowr

CCN by EL

Enab, Disab

DTR Alarm

Enab, Disab

Async

Sync

Enab, Disab

AsyncBit/Char

6, 7, 8, 9, 10

Stop Bits

1, 2

Overspeed

1.0, 2.3

{

V.32 DBM only

{{{

Only if Diag Type set to NonD

}

Only if Primary Core set to Yes

} }

Only at the Control

Diagnostic DBM

Value

Diag Type

NonD, Disr, None

2nd Ch(bps)

{{{

100, 400, 800, 1200, 1600

Diagnostic General

Value

Position

Cntrl, Trib

RemoteDiag

V.54

{

, Enhan

Link Delay

} }

0s, 1s, 2s, 5s, 10s, 20s, 50s

Packet Delay

} }

0s, 1s

,

2s, 5s

Backup

Value

Auto Bckup

Enab, Disab

Backup Dir

(Chang)

(1–10)

BckupOnCMI

Enab, Disab

AutoRestor

Enab, Disab

NtwkTimOut

(Chang)

min and sec (1 to 30 min)

RestorTimOut

(Chang)

min and sec

(1 to 60 min)

TriesTimeOut

(Chang)

min and sec (1 to 60 min)

MultiCall

Enab, Disab

Backup Directory

Dial String

1

2

3

4

5

6

7

8

9

10
