COMSPHERE DualFlow Data Service Units
F-2 December 1996 3615-A2-GB20-20
Equipment Comcode
Feature/Part No.
G = Factory Install.
F = Field Install.
Model 3616 Digital (DDS) Network Cables 1
50-pin to eight 6-pin Multiple Network Interface Adapter
(Model 3616 in Canada)
50-pin to eight 8-pin Multiple Network Interface Adapter
(Model 3616 in U.S.A.)
1.5 i — 3000-F1-009
1.5 i — 3600-F2-503
106459621
106303837
Model 3616 Dial (PSTN) Network Cable Adapter 1
50-pin to eight 6-pin RJ11C/Permissive Cable
50-pin to eight 8-pin RJ45S/Programmable Cable
1.5 i — 3600-F2-505
1.5
i
— 3600-F2-504
106459928
106459548
3600 Hubbing Device 3600-F3-300 106744683
NMS Adapter Cable/Diagnostic Extension 3000-F2-510 106768690
NMS EIA-232-D Interface Connector
Central-site 25-pin to 6-pin (873A) Adapter
Remote-site 25-pin to 6-pin Adapter 4400-F1-594
6821-F1-518 106473150
106261464
NMS 6-pin Modular Cable – M6BJ 3 i — 4400-F1-510
10 i — 4400-F1-511
25
i
— 4400-F1-512
106472830
106472848
106472855
COMSPHERE 3000 Series Carrier, Installation Manual 3000-M3-001 —
COMSPHERE – 48 Vdc Central Office Power Unit, Installation Manual 3000-A2-GB41 —
COMSPHERE DualFlow Data Service Units, Models 3615 and 3616,
User’s Guide 3615-A2-GB20 —
COMSPHERE DualFlow Data Service Units, Models 3615 and 3616,
Documentation Replacement 3615-A2-GB21 —
1 These cables are extended using a 3000-F1-013/014 cable.
