36 Basic Operation Instructions
Synergy Seat www.pridemobility.com
MANUAL RECLINE OPTION
If your Synergy Seat includes Pride’s Manual Recline Option, you can
adjust the seatback to angles ranging from the minimum recline position
(90° from the seat base) to the maximum recline position (180° from the seat
base). See figure 33. When the seat is reclined past 110°, an inhibit switch
will cut power to the motors of your power chair. Returning the seat to an
angle of less than 110° degrees will restore power to the motors.
To recline the seatback:
1. Grasp the handles at the top of the seatback.
2. Squeeze both of the recline release handles simultaneously, and position
the seatback to the desired angle. See figure 34.
3. Release the handles to lock the seatback into position.
Recline Release Lever
Figure 33. Minimum and Maximum Recline Angles
