Basic Operation Instructions 23
www.pridemobility.com Synergy Seat
-30
0
30
WHITE
DOT
ADJUSTABLE DIAL ADJUSTABLE DIAL ADJUSTABLE DIAL
WARNING! Do not attempt to lift or move your power chair
or seating system by any of its removable parts, including
the armrests, front riggings, seat cushions, seatback,
shrouds, or controller. Use only solid, non-removable frame
components to lift or move your power chair or seating
system.
WARNING! Avoid putting all of your weight on the power
chair armrests and do not use the armrests for weight
bearing purposes, such as transfers. Such use may cause
the power chair to tip, resulting in a fall from the power
chair and personal injury.
WARNING! The controller and controller bracket are non-
load bearing items on your seating system. Do not use the
controller or controller bracket for weight bearing
purposes, such as transfers. Such use may cause damage
to those components, resulting in a fall from the seating
system and personal injury.
Cantilever Armrests
The Cantilever Armrests are attached to the back canes and are designed to
lift up and out of the way for easier transfer onto and off of the power chair.
Both the angle and the height can be adjusted on the Cantilever Armrests.
To adjust the armrest angle:
1. Raise the armrest perpendicular to the floor.
Figure 15. Cantilever Armrests Angle Adjustment
