WR3000

4-Port Wireless DSL/Cable Router

1.4.3 Connecting the WR3000 to Your Computer for Initial Conﬁ guration
The rear panel of the WR3000 contains several ports, as described below:

For initial setup, you should have:

• The power adapter plugged into the WR3000 as shown, and this adapter plugged into a

surge-protected electrical outlet.

• Your Cable or DSL modem’s Ethernet cable plugged into the Internet In port as shown above.

• An Ethernet cable plugged into the router port 1 as shown above, and the other end of this cable

plugged into your computer’s Ethernet port.

Now proceed to the next page to begin setting up your WR3000.

Plug the AC Adapter

into this port.

Plug your computer’s Ethernet

cable into Port 1. The

remaining ports can to be used

with other computers in a hard-

wired router fashion

Plug your cable or DSL

modem’s Ethernet

Cable into this port
