Chapter 3: Setup
51
• Other
4. Click the Update button.
Or check the Automatic Update box and updates will occur automatically.
The following parameters display:
•
Disk Arrays – The number of physical drives in the disk array, their ID
numbers, configurable capacity and the number of logical drives to be
created
• Logical Drives – The ID number of the logical drive(s), their RAID level,
capacity and stripe size
• Spare Drives – The physical drive ID number of the dedicated hot spare
assigned to this disk array
5. If you accept these parameters, proceed to the next step.
If you do NOT accept these parameters, review and modify your selections
in the previous steps.
6. When you are done, click the Submit button.
The new disk array appears in the Disk Array List on the Information tab.
Proceed to logical drive creation (page 48).
Advanced Option
The Disk Array Advanced Creation option enables you to directly specify all
parameters for a new disk array. One logical drive will be made automatically
when you create the disk array. If you select less than the total available capacity,
you can use the remaining space to create additional logical drives at a later time.
To create a new disk array:
